Product Description
A solution specifically for the construction of small and micro data centers. All subsystems of the data center are integrated in the cabinet, which integrates power distribution, UPS, monitoring, cooling and cabinet systems. Among them, the integrated infrastructure cabinet integrates power distribution, UPS, rack air conditioning, and monitoring modules, which greatly saves room space. IT cabinets are equipped with infrastructure such as flexible line systems and management systems on both sides of the integrated infrastructure cabinet, with a compact layout and flexible expansion capacity.
The cooling and electric control integration is pre-integrated in a cabinet, and the on-site installation only needs to be simple and the cabinet is installed, and the construction time is only 4 hours.
Remote monitoring, centralized monitoring of multi-module unified network management, unattended operation
Rack air conditioning, saving at least one cabinet installation space
DC variable frequency cooling, optional hot and cold channels, PUE as low as 1.37
10% load in the equipment room can be dehumidified lightly to avoid the risk of condensation in the equipment room
Real-time monitoring of battery voltage, internal resistance and temperature, intelligent shutdown for overheating to prevent fire
Product characteristics | |
---|---|
Server Cabinet | 3 sets of standard 600 * 1200 * 42U cabinets, providing 108U of independent installation space 5 sets of standard 600 * 1200 * 42U cabinets, providing 182U of independent installation space |
Precision air conditioner | 1 set of 8kW precision air conditioning 1 set of 15kW precision air conditioning |
UPS |
1 set of 10KVA rack mounted UPS |
Battery pack | 1 set of backup power for 30 minutes |
PDU | 3 sets of single-phase 12 channel 10A and 4 channel 16A outputs 5 sets of single-phase 12 channel 10A and 4 channel 16A outputs |
Power Distribution Module | 1 set of modular power distribution unit with built-in smart meter, MODBUS protocol, UPS bypass interlocking function |
Monitoring Module | 1 set including monitoring unit, fire protection unit, smoke sensor, temperature and humidity sensor, and water immersion detector |
Alarm form | Sound and light alarm and SMS alarm |
Dimension | 1800×1200x2000mm 3000×1200X2000mm |
